WOYO PDR009 Auto Body Repair Tool PDR 009 Induction Heater Paintless Dent Metal Repair Removing Tool

Please select the correct plug which you need when you make the order

1.US plug
2.EU Plug
3.AU Plug

Note: There are EU Plug, US Plug and AU Plug in our store. And the Instrument has AC 100-120V and AC 220-240V. Please leave a message what you need.

WOYO PDR009 Paintless Dent Repair For Aluminum

The WOYO PDR009 is a mobile, handheld magnetic induction unit designed for paintless dent removal from panels using rapid, focused heating induction.Unit can also be used to shrink stretched metal.Fast to repair and easy to use are the biggest advantages of it.The unit has several settings that can be adjusted depending on its application.A quick, easy and fast application is the key to any repair.

WOYO PDR009 Features:

1.WOYO PDR009 is easy to use, any worker with a background in metal composition can master it in 3 minutes.
2.Independent Time & Power Mode, More Setting Options.
3. Adjustable Beep Sound to Avoid Interference ( Close, Up, Down).
4. Features a large color display for precise control and monitoring progress in real-time.
5. Application: soft dent, dent in non-marginal area.
6. Repair method: With rapid, focused heating induction on the dent surrounding via the repair handle, the dent stretched and repaired by itself.
7. Time control mode: Repair dark color dent suggested.
The working time can be preset while the power is always 100%, meaning if you want to heat for example 0.5 sec, then you can preset this time and it will stop working after the set time. The time setting range from 0.5 sec to 4 sec. This can be helpful in the dent removal application to avoid burning the dent. We also added an extra dial ” MAX” to extend the working time as you want.
8. Power control mode: Repair light color dent suggested.
The power can be preset from 20% to 100%. Using the power control mode, the working time can be adjusted by ON/OFF on the repair handle.
9. Certificate CE FCC ROHS PSE.

Main Characters：

1. Startup auto-checking system (input voltage and frequency)
2. Independent Time & Power mode, more setting options
3. Adjustable beep sound (close/up/down)
4. Color display (standby/running status)
5. Smaller mains size and lightweight
6. Comes with plastic tool case

Installation:

1. Connect the cord to the repair head and PDR009 main.Aim at the location socket and insert one end of the cord, turn the end clockwise to tighten the cord securely.
2. Connect the power cord to the backside of the PDR009 main.
3. Make sure that all the cords are well connected before connect the machine to the power socket.Turn the switch on at the backside of the PDR009 main.

Accessory List：

1 x PDR009
1 x Main Cable (3M)
1 x Power Cable (1.8M)
1 x Repair Handle
1 x Manual
1 x Tool Case

Frquently Asked Questions:

1.How to work? ( What is the theory?)

Unlike traditional PDR, the PDR adopts magnetic induction heating and releases the dents tension, then adsorbs the depression parts, and finally recovers to original state.

2.What are the differences between PDR and traditional dent remove tool?

Free disassembly

Traditional repair tools use hook, reach into the interior of sheet metal, and then pull the dent parts. Disassembling auto doors or windows may be necessary.

But, PDR can work directly on the dent parts.

Efficiency increased significantly

PDR may take 30s-3min.

the traditional repair tool takes at least 30 minutes. Besides the spray shall take 24 hours

Exquisite workmanship

the dent part is smooth after PDR. the traditional repair tools may leave some small bumps.

What kind of dent can be repaired
Adaptive Range

Note: The amount of heat and the length of use have an effect on the color of the paint, especially the white car.
