WOYO CAN Bus Circuit Tester OBD2 16 Pin BreakOut Box Detecter

WOYO CTB007 CAN Tester Box Pin Settings Diagnostic Tool is a CAN Bus circuit tester compatible with 12 and 24 volt systems, It is The OBD2 16Pin Break Out Box Communication Detection.

WOYO CAN Bus Circuit Tester Characters:

1.CAN Tester Box is a CAN Bus circuit tester compatible with 12 and 24 volt systems;
2.Testing DLC (OBD port) if any error before connecting connecting other diagnostic equipment to DLC, such as pin short circuit and polarity reverse connection ;
3.Real-time display of communication signals ( such as communication protocol signals ) on the allocated
pins which can quickly locate faults and replace the voltage measurement function of digital multi-meter ;
4.Fastly connect 16 pins during vehicle maintenance diagnosis;
5.Monitoring input voltage of OBD when burning module, high and low voltage alarm;
6.Quick short obd porsche communication 3-7;
Short-circuit obd VW key all lost 1-6;
Short-circuit obd Mitsubishi remote control 1-4;
Short-circuit obd Toyota sync 4-13;
7.OBD workbench CAN boot box;
8.Replace the battery tool;

Specifications:

Input Voltage:9.0-32.0VDC
Maximum Load:2.0A
Resolution:0.1V
Overload Protection:Yes, PTC Fuse (Self-Healing)
Reverse Polarity Protection:Yes,LED On Pin 4&5 Turn Red
Protocol Standard:PWM(J1850)、VPW（J1850）、ISO 9141-2、DIS/ISO 14230-4、CAN(J-2284)
Operating Temperature:0℃-50℃，Humidity<70%
Banana Socket:16P*2.0mm
OBD Cable Length:70cm(27.5inch)
